DLE Engine - DLE-222cc Gas engine

This is the DLE 222cc Gasoline Powered Engine with Electronic Ignition.

FEATURES: Dual carburetors for maximimum performance
          Double V-type reed valve bottom induction
          Six bolt prop hub
          Fully automatic electronic ignition
          Two year limited warranty through Hobby Services beginning at date
            of purchase

INCLUDES: Engine, four spark plugs, standoffs, ignition, instruction manual
            two mufflers, prop hub and throttle arm extension

REQUIRES: 87 octane gasoline
          2-cycle oil, mix ratio for this engine is 30 parts gas to one part
            oil and must be followed exactly for warranty consideration
            and optimum performance
          Ignition Battery: Two 4.8 - 6V NiCd or NiMH batteries OR 7.4V LiPo
            Packs or 6.6V LiFe packs (LiPo & LiFe require voltage regulator)
            (separate receiver style pack can be used)
          Propeller: 32x10, 32x12, 34x10
          Field Equipment

SPECS:      Engine;
          Output Power: 21.5 HP at 7,500 RPM
          RPM Range: 1,000 - 7,500
          Idle Speed: 1000 RPM
          Displacement: 13.6 cu in (222.5cc)
          Bore: 1.77" (45mm)
          Stroke: 1.38" (35mm)
          Compression Ratio: 7.6:1
          Engine Weight: 10.9lbs (174.6oz) (4950g)
          Total Width Including Both Cylinder Heads: 10.1" (258mm) not
            including spark plugs
          Distance between Horizontal Mounting Hole Centers: 3.2" (81mm)
          Distance between Vertical Mounting Hole Centers: 3.6" (91mm)
          Height of Entire Mounting Plate: 4.2" (107mm)
          Widtht of Entire Mounting Plate: 3.8" (96mm)
          Length from Mounting Plate to Front Bearing: 8.97" (228mm)
          Length from Mounting Plate to Prop Hub: 10.1" (258mm)
          Height from Crankcase to top of Carburetors: 6.2" (157mm)
          Distance between Muffler Mounting Hole Centers: 1.6" (40.5mm)
          Height from Crankcase to end of Muffler Pipe Outlet: 11.2" (286mm)
          Muffler Outlet Diameter: 1.2" (30mm)
          Cylinder Head Exhaust Outlet Height: 0.51" (13mm)
          Cylinder Head Exhaust Outlet Width: 1.1" (27mm)
          Muffler Can Length: 8.4" (214mm)
          Muffler Can Diameter: 2" (50mm)
          Exhaust Pipe Diameter: 1.2" (31mm)
          Exhaust Pipe Length: 6" (152mm)
          Gasoline/Oil Mixture: 30:1
          Gasoline Octane Rating: 87-93
          Recommended Propellers: 26x12, 28x10
          Spark Plugs: DLE 222-Q26 (DLEG2226) or equivalent
            Carburetor;
            Carburetor is preset from the factory but may require slight
            needle adjustment depending on altitude
          Low Speed Needle: 1.5 turns from closed
          High Speed Needle: 1.5 turns from closed

COMMENTS: To avoid permanent damage to the electronic ignition system, NEVER
            turn your DLE engine over with the system switched on and the plug
            not installed.
