Ephil - 76cc Twin Gasoline Engine - X-76cc-T

Skip to the end of the images gallery

Skip to the beginning of the images gallery

CAD $840.99

Availability: Out of stock

SKU:

23125

Distributor Number

EPHX076TE

Manufacturer Number

X076TE

Power meets precision with the EPHIL X-76cc-T — a robust 76 cc twin-cylinder gasoline engine delivering around 9 HP of performance. Equipped with electronic ignition and premium spark plugs, it’s built for serious RC fixed-wing aircraft that demand dependable starts, smooth throttle response, and high thrust. Whether you’re flying sport, scale or aerobatic models, the X-76cc-T brings modern convenience and strong engine dynamics to your build.

Usage

Ideal for large fixed-wing RC aircraft (wingspan approx. 2.4 m+ or heavier setups) where a 76 cc displacement is justified.
Includes electronic ignition and spark plugs for cleaner, more reliable engine starts — fewer hassles at the field.
Recommended propellers include sizes like 22×10, 23×8, 23×10, 24×8 (choose based on model weight and altitude).
Use a proper fuel / oil mix (typically 30 :1 gasoline to 2-stroke oil) and ensure the ignition supply voltage is in the 6-14 V range.
Ensure your airframe provides strong mounting (firewall, vibration isolation) and sufficient cooling airflow — this engine class generates significant heat and torque.
Perform a recommended break-in period before full throttle operation: moderate throttle, rich mixture, varying loads to ensure long-term reliability.

Be the first to review this product

Details

Technical Specifications

EPHIL X-76cc-T

Displacement: 76 cc (4.64 cu in)
Performance: 9.0 HP
Speed Range: 1600 – 7300 RPM (Test Propeller – 24×8)
Bore: 39 mm (1.54 in)
Stroke: 32.5 mm (1.28 in)

Static Thrust:

• 18.5 kg @ 100 m ALT (40.8 lb @ 328 ft)
• 16.8 kg @ 1800 m ALT (37.1 lb @ 5900 ft)
Compression Ratio: 9 : 1
Lubrication Ratio: 30 : 1 (Fuel : 2-Stroke Motor Oil)
Ignition Voltage: 6 – 14 V
Spark Plug Type: CM6 Iridium Spark Plug

Recommended Propellers: 22×10 | 23×8 | 23×10 | 24×8

Component Weights:
• Main Engine – 1689 g
• Muffler Set – 174 g (L&R Mufflers + Screws)
• Aluminum Standoffs – 72 g
• Spark Plugs – 27 g (13.5 g × 2 CM6)
• CDI (Ignition) – 173 g

Total Weight: 2134 g (4.7 lb)
