Ephil - 38cc Rear exhaust Gasoline Engine - X-38cc-R

Skip to the end of the images gallery

Skip to the beginning of the images gallery

CAD $565.59

Availability: Out of stock

SKU:

23123

Distributor Number

EPHX038RE

Manufacturer Number

X038RE

Push your model aircraft performance to the next level with the EPHIL X-38cc-R — a robust 38 cc gasoline engine designed for ultimate reliability and power. With its electronic ignition and precision engineering, this engine offers serious thrust, smooth starts and exceptional endurance. Whether you’re flying scale, sport or aerobatic, the X-38cc-R delivers the muscle you need to dominate the sky.

Usage Notes

Ideal for large fixed-wing RC aircraft where a 38 cc powerplant is warranted.
Bundled with electronic ignition (spark plug included) for consistent startup and dependable operation.
Ensure your airframe supports this size engine: proper firewall, cooling airflow and vibration isolation are key.
Choose a propeller size in the recommended range (e.g., 19×8, 20×10) to match the engine’s output.
Use a clean fuel mix and follow the break-in period as per manufacturer guidelines to maximize engine life.
Pair with ignition power supply (6-14 V) and ensure electrical/ESC setup is compatible.
Regularly inspect mounting and connections — large engines produce significant vibration and thermal load.

Be the first to review this product

Details

Technical Specifications

Model: X-38cc-R
Displacement: 38 cc (2.33 cu in)
Performance: 4.2 HP
Speed Range: 1800 – 7300 RPM (Tested with 20×8 propeller)
Bore: 39 mm (1.54 in)
Stroke: 32.5 mm (1.28 in)
Compression Ratio: 9 : 1

Static Thrust:

9.9 kg @ 100 m altitude (21.8 lb @ 328 ft)
8.2 kg @ 1800 m altitude (18.1 lb @ 5900 ft)
Lubrication Ratio: 30 : 1 (Fuel : 2-stroke motor oil)
Ignition Voltage: 6 – 14 V
Spark Plug Type: CM6 Iridium spark plug

Recommended Propellers: 19×8 | 19×10 | 20×8 | 20×10

Component Weights:

Main Engine: 1040 g
Muffler Set: 73 g
Aluminum Standoff Set: 100 g
Spark Plug: 13.5 g
CDI (Ignition): 104 g
Total Weight: 1330.5 g (2.93 lb)
